PC終端與NMEA 2000信息轉譯網關 | |||
輸入?yún)f(xié)議: | NMEA 2000 | 輸出協議: | PC USB |
協議轉換方向: | 雙向 | 數據存儲功能: | 無 |
RS232/ RS422接口: | 兼容 | RS485接口: | 不兼容 |
傳輸速度: | · ISO版 4800 to 115200 Baud · USB版 4800 to 230400 Baud |
供電要求: | ISO版NMEA 2000接口 · 供應電壓-9.5~35V DC · 供應電流-35mA @ 12V DC, Max 50mA USB版NMEA 2000接口 · 供應電壓-9~29V DC · 供應電流-15mA @ 12V DC, Max 50mA USB主機端口 · 供應電流-85mA @ 5V DC |
電氣隔離: | · ISO版 2500V input to ground, 1500V output to ground using ISO-Drive , Galvanic Isolation · USB版 2500V input to ground, Galvanic Isolation |
診斷提示: | Use with our FREE NMEA Reader to help diagnose |
防護等級: | IP54 | 工作溫度: | -20°C to +55°C |
環境溫度: | -30°C to +70°C | 環境濕度: | 0 - 93% RH |
質保年限: | 3年 | 性能特點: | ·Removes the need for a separate power supply, reducing installation time and complexity · Configure and flash-update Acti- sense products on the NMEA 2000? bus · 1500V isolation on both input & output · Provides a rule-enforcing firewall between the PC andNMEA 2000? bus |
-供應商聯系方式- | |||||
![]() |
公司名稱: | Active Research Ltd T/A Actisense |
![]() |
聯系人姓名: | Justin Cohen |
公司地址: | 21 Harwell Road, Poole, BH17 0GE, UK | 聯系人電話: | +44 01202746682 | ||
聯系人郵箱: | sales@actisense.com |
