QSK60系列主推發(fā)動機 |
額定功率: |
1864kw |
額定轉速: |
1900rpm |
缸徑: |
159mm |
沖程: |
190mm |
排量: |
60.2L |
配置: |
D593009MX03 |
進氣方式: |
Turbocharged/LTA |
最大扭矩: |
9839N.M(轉速為1500rpm下的最大扭矩) |
壓縮比: |
14.5 |
額定扭矩: |
9369N.M |
廢氣排溫: |
399℃(Turbine out)/589℃(Manifold) |
廢氣體積流量: |
6274L/S |
噪聲等級: |
102~107dBA@1m |
平均效應壓力: |
1957kPa(Brake) |
點火順序: |
2-1-6-5-4-3-10-7-16-15-12-11-14-13-8-9 |
活塞速度: |
12.0m/s |
燃油系統(tǒng): |
Modular Common Rail (MCRS) with C3.0 Injectors |
冷卻系統(tǒng): |
水冷 |
排放標準: |
IMO Tier I (One) NOx requirements of International Maritime Organization (IMO), MARPOL 73/78 Annex VI, Regulation 13
EPA Tier 2 - Model year requirements of the EPA marine regulation (40CFR94)
EU Stage IIIa - EC Nonroad Mobile Machinery Directive (2004/26/EC) |
|
|
