QSK19系列主推發動機 |
額定功率: |
567kw |
額定轉速: |
2100rpm |
缸徑: |
159mm |
沖程: |
159mm |
排量: |
18.9L |
配置: |
D193102MX03 |
進氣方式: |
Turbocharged/LTA |
最大扭矩: |
3078N.M(轉速為1400rpm下的最大扭矩) |
壓縮比: |
15 |
額定扭矩: |
2577N.M |
廢氣排溫: |
427℃(Turbine out)/605℃(Manifold) |
廢氣體積流量: |
1975L/S |
噪聲等級: |
82~101dBA@1m |
平均效應壓力: |
1718kPa(Brake)/3441kPa(Indicated) |
點火順序: |
1-5-3-6-2-4 |
活塞速度: |
11.1m/s |
燃油系統: |
Modular Common Rail (MCRS) with C3.0 Injectors |
冷卻系統: |
水冷 |
排放標準: |
EPA Tier 2-Model year requirements of the EPA marine regulation(40CFR94);EU Stage IIIa-EC Nonroad Mobile Machinery Directive(2004/26/EC);IMO Tier II(Two)NOx requirements of International Maritime Organization(IMO),MARPOL 73/78 Annex VI,Regulation 13 |
|
|
